Adjusting Nut Scaffolding Steel Props , Steel Shuttering Props Cast Iron Sleeve

  • 1
  • 2
  • 3

Brand Name : HORIZON

Model Number : SCAFFOLDING PROP

Certification : SGS

Place of Origin : CHINA

MOQ : 2000 pcs

Price : pls ask HORIZON

Payment Terms : L/C, T/T

Supply Ability : 20000 pcs per week

Delivery Time : 15-25 days

Packaging Details : pallets, bundles, bulk

Material : Q235, steel pipe

OEM : Available

finishing : electric galvanized, hdg

Standard : EN1065

Size : from 1.7m to 5.5m

Application : for supporting slab shuttering

Tube size : diameter 56mm, 48mm

Load capacity : 20KN

Contact Now

Scaffolding Steel Props With Adjusting Nut and Sleeve of Cast Iron

Scaffolding steel props are used to support slab shutterings in buildings construction, with working height range from 1.7m up to 5,50 m.

The inner tube is Ø 48.3 mm (thickness from 2 mm to 4.0mm) with holes to adjust the working height with help of the lock pin.

The outer tube is Ø57 mm (thickness from 1.6 mm to 2.5mm) with reinforcement at foot.

The pin diameter is between 12 and 14 mm, with a special design that does not allow its fall.

Two end plates, upper and lower plates, serve to give stability to the steel prop.

The thread is covered by a cast iron cup-type nut that has 2 side handles for easy handling.

A steel ring plate is also equipped on the nut that prevents concrete materials falling into the nut and get stuck.

The adjusting nut is made from cast iron, with high strength loading capacity.

Height Range

Outer tube (mm)

Inner tube (mm)

Thickness (mm)

 Adjusting device
1.7m-3.0m 60 / 57 / 48 48 / 40 1.6-4.0 Ext. thread / Int. thread
2.0m-3.6m 60 / 57 / 48 48 / 40 1.6-4.0 Ext. thread / Int. thread
2.2m-4.0m 60 / 57 / 48 48 / 40 1.6-4.0 Ext. thread / Int. thread
2.5m-4.5m 60 / 57 / 48 48 / 40 1.6-4.0 Ext. thread / Int. thread
3.0m-5.5m 60 / 57 / 48 48 / 40 1.6-4.0 Ext. thread / Int. thread
