Professional Tie Rod Formwork Accessories 145KN Tensile Loading Capacity

Name: Professional Tie Rod Formwork Accessories 145KN Tensile Loading Capacity
Brand: HORIZON
Price: 1 USD

Brand Name : HORIZON

Model Number : HORIZON FORMTIE

Certification : SGS

Place of Origin : CHINA

MOQ : 10 tons

Price : pls ask HORIZON

Payment Terms : L/C, T/T

Supply Ability : 100 tons per week

Delivery Time : 15-25 days

Packaging Details : pallets, bundles, bulk

Material : 45# steel rod

OEM : Available

finishing : natrual colour, galvanized

Size : dia 15/17mm, 20/22mm

Application : to fasten formwork panels

Length : L=6m or as per request

Samples : available

Contact Now

Dywidag Thread Formwork Tie Rod with 145KN Tensile Loading Capacity

Formwork tie rod performs as the most important member in tie rod system, fastening formwork panels. Usually used together with wing nut, waler plate, water stop, etc. Also it is enbeded in concrete used as lost part.

Tie rod diameter	15/17mm, minor dia 15mm and major dia 17mm
Max. load	145KN
Length	Any length within L=6 meters
Material	45# steel, equal to AISI 1045
Other sizes	available n request, such as D20mm, D22mm, etc.

Part Name	Specification	Weight (kg)	Remark
Tie-rod	D15 D20	1.52 kg/m 2.71 kg/m	L=6m; Special length available upon request.
Wing nut	D15 D20	0.35 0.70	For tie-rod D15 / D20
Super plate	D15	1.28	Used in case of tie-rod and formwork panels are not vertical.
3-lug wing nut	D15 D20	0.97 0.78	For tie-rod D15; For tie-rod D20
Waling plate	120 x 120 x 6, Φ19 120 x 120 x 8, Φ19	0.65 0.85	For tie-rod and nut D15; galvanized
Water stopper	D15 D20	0.55 0.72	Used in water resistant wall; With tie-rod D15 / D20
Anchor plate	D20	0.95	Embedded in concrete as lost part

Professional Tie Rod Formwork Accessories 145KN Tensile Loading Capacity
